UNIVERTOR AC-1

Description

Year of manufacture: 2011

Retrofit class: Function tested.

This series is a very fast, multi-functional single-spindle pick-up lathe in modular design with vertical spindle-slide arrangement. The machine is currently directed with a rotary turning unit with drive for 8-position disc turret for use in hard turning.

The machine is a demonstration machine.

Technical data

Working/loading space

Clamping diameter
mm
210
Max. Swing diameter
mm
400
Control Siemens 840 D
Slide travel X-axis
mm
1.130
Rapid traverse X-axis
m/min
60
Z-axis slide path
mm
240
rapid traverse Z-axis
m/min
30
Carriage travel Y-axis
mm
11

Motor spindle

Spindle bearing diameter
mm
90
spindle head according to DIN 55026
Size A6
Drive power 100% ED
kW
18
Drive power 40% ED
kW
23
Speed range infinitely variable
rpm
6.000
Torque at 100%
Nm
115
Torque at 40%
Nm
150

Tool turret

12-station disc turret with tool drive
Tool holder Radial 40H6 DIN 69880
Total connected load
KVA
58
Machine weigh
t
8
Length x width x heigh
m
5,15 x 4,1 x 2,4
Operating hours
h
2.002
Compressed air min
bar
6

Equipment

NC Shuttle
Blum probe
3 jaw chuck
Chip container
